How to Choose Floor Panels for Electric Underfloor Heating?

Electric underfloor heating from TERMOFOL is a solution that combines user comfort with modern heating technology. A key element that determines the efficiency and durability of such a system is the selection of appropriate floor panels. The panels must meet specific technical requirements to work with underfloor heating, ensuring safety, energy efficiency, and aesthetics.

In this article, we present detailed information about floor panels compatible with electric underfloor heating and the principles of their use with systems based on heating films from TERMOFOL.

Declaration of Conformity and Safety of Use

Floor panels that can be used with TERMOFOL electric underfloor heating have a declaration of conformity from their manufacturers. This means that they have undergone detailed technical tests confirming their compatibility with the heating system. The declaration of conformity guarantees that the flooring materials will not be damaged by heat and that the heating system will operate at maximum efficiency.

Why is the declaration of conformity important?

• Safety: Panels with confirmed compliance are resistant to high temperatures and their fluctuations.
• Thermal efficiency: Well-chosen materials ensure even heat conduction, eliminating energy losses.
• Longevity: Both the heating system and the flooring will operate for many years without failure.

Technical Requirements for Floor Panels

When choosing floor panels, several key parameters should be considered:

1. Thickness of the panels

Panels intended for use with underfloor heating should have a thickness of 6 mm to a maximum of 10 mm. Thinner panels conduct heat better, which increases the efficiency of the system. Conversely, overly thick panels can significantly limit heat transfer and increase operating costs.

2. Thermal resistance

The thermal resistance of the panels and underlay should be a maximum of 0.15 m²K/W. This is the value recommended by the TERMOFOL system manufacturer, which guarantees optimal heat flow. Thermal resistance is a key indicator of the efficiency of the entire heating system.

• Tip: When choosing an underlay, ensure that it is dedicated to underfloor heating systems and has a low thermal resistance value.

3. Dimensional stability

Panels should exhibit high dimensional stability. This means that the material will not deform under temperature changes. Unstable panels can cause unevenness and damage to both the flooring and the heating system.

4. Temperature resistance

Panels compatible with TERMOFOL underfloor heating are resistant to temperatures up to 27°C – 29°C. This is the range in which most electric heating systems operate. It is important to ensure that the selected panels meet these requirements.

Manufacturers of Floor Panels Compatible with Underfloor Heating

There are many manufacturers of floor panels on the market that work excellently with TERMOFOL electric underfloor heating. This is confirmed by tests and declarations of conformity.

• WENINGER Panels
• Kronopol Panels
• DECORA Panels
• Barlinek Panels
• Swiss Krono Panels
• Foliarex Panels
• EGGER Panels
• CLASSEN Panels
• Multicontract Panels
• Korner Panels

Tip: Before purchasing panels, check their declaration of conformity with heating systems such as TERMOFOL.

Installation of Floor Panels with the TERMOFOL System

To ensure trouble-free installation and use, several key principles should be followed:

1. Preparation of the substrate

• The substrate should be dry, clean, and level.
• Thermal insulation should be laid on the substrate to direct heat upwards, minimizing losses.

2. Installation of heating film

• TERMOFOL films are laid on the insulation layer, leaving small gaps from the walls.
• A protective conduit for the temperature sensor should be installed under the heating film.

3. Installing the panels

• Panels are laid on the heating film using vapor barrier film, applying the "floating" system (without gluing).
• It is important to maintain appropriate expansion gaps around the walls to allow for the natural movement of the flooring.

4. Testing the heating system

• Before laying the panels, it is advisable to test the operation of the TERMOFOL system to ensure that all components are functioning correctly.

More information about installing heating films under floating panels can be found on our website and in a special INSTRUCTIONAL VIDEO.

Advantages of Floor Panels Compatible with TERMOFOL

• Energy efficiency: Well-chosen panels ensure quick heating and even distribution of heat.
• Safety: Materials with a declaration of conformity are resistant to overheating and damage.
• Comfort: A warm floor enhances the comfort of living and commercial spaces.

Common Mistakes and How to Avoid Them

1. Inappropriate panels: Panels with too high thermal resistance significantly reduce the efficiency of the system.
2. Poor substrate preparation: Unevenness and moisture can lead to damage to the panels or heating film.
3. Damage to the heating film during installation
4. Cutting or piercing the heating film with sharp tools or careless handling of materials can lead to system failure.
   Exercise particular caution when cutting and fitting underlays or panels. Never use sharp tools directly on the surface of the film. Check the heating film after each installation operation to ensure it has not been damaged.
5. Incorrect connection of the heating system – Improper electrical connections, lack of a temperature sensor, or incorrect thermostat configuration can lead to overheating of the system, its failure, or even fire hazards. All work related to connecting the heating system should be entrusted to a qualified electrician with the appropriate qualifications. Install the temperature sensor in a protective conduit to allow for easy replacement in the future. Check the correctness of the installation before laying the panels by conducting system tests.
6. Skipping the system test before panel installation – Failing to test the heating system before laying the panels may mean that any faults are only noticed after the installation is complete, which involves the need to dismantle the flooring. Before starting to lay the panels, check the operation of the heating system, including the resistance of the wires and the functioning of the thermostat.

Selecting the right floor panels is key to the efficiency and durability of TERMOFOL electric underfloor heating. Floor panels with a declaration of conformity guarantee safety, comfort, and energy efficiency. Adhering to installation guidelines and using materials recommended by the manufacturer will ensure reliable operation of the system for many years.

For more information about compatible materials and heating systems, visit https://termofol.pl/warunki-gwarancji/
